MAZDA RX TWIN-ROTOR WANKEL ENGINE cutaway model
Accurate section of the most common Mazda RX Wankel engine, clearly showing the following main components:
• Drive shaft with flywheel
• Twin-rotor
• Suction and exhaust channels
• Chain-driven oil pump
• Water pump with thermostatic valve
• Electronic injection
• Twin-spark ignition
• The Twin Rotor Wankel cutaway engine mounted on the stand with the wheels.
