Industrial Parts Washer Teijo C-1600 HH-KD

High-performance, single-stage industrial parts washer designed for efficient cleaning of large and heavy components. This model combines a robust structure with high washing capacity and user-friendly operation, making it ideal for heavy-duty applications in industrial and maintenance environments.
Technical Specifications:
Washing chamber diameter: 1600 mm
Washing chamber height: 930 mm
Maximum load capacity: 1000 kg
Pump flow rate: 470 L/min
Pump pressure: 4 bar
Pump model: FHE 40-200 / 55
Pump motor power: 5.5 kW
Heating power: 2 × 12 kW (total 24 kW)
Total electrical power: 25 kW
Power supply: 3 × 400 V / 50 Hz
Control voltage: 230 V
Tank volume: 1400 liters
External dimensions (L × W × H): 2200 × 2800 × 2300 mm
Weight: 1100 kg
Functions and Features:
Washing system: Dual rotating spray pipe ensures even and thorough cleaning of all surfaces
Door mechanism: Mechanically operated front door with integrated safety lock
Control system: Automatic wash cycle with programmable timer
Insulation: Thermal and acoustic insulation for improved energy efficiency and reduced noise levels
Optional Features: Automatic water refill, detergent dosing, oil separation, and steam extraction
